China Ruifeng AG200 YAMAHA Motorcycle is not only a reliable means of transportation, but also a partner that can bring fun and satisfaction. Its wide seat and comfortable handling performance allow the driver to maintain a good state during long-term driving. At the same time, the various practical functions of the vehicle also greatly improve the driver's work efficiency and convenience.
In terms of power, the AG200 YAMAHA Motorcycle is equipped with an air-cooled four-stroke SOHC 2-valve single-cylinder engine. This engine has the characteristics of simple structure and strong durability. The total displacement is 196cc, the maximum output power reaches 14.3PS/7500rpm, and the maximum torque is 1.5kgf·m/6500rpm. Such a power configuration enables the AG200 YAMAHA Motorcycle to cope with various complex terrains with ease.
In order to cope with muddy, sandy and other road conditions in harsh environments such as pastures, the AG200 YAMAHA Motorcycle is equipped with pineapple tires. This tire has excellent grip and wear resistance, and can maintain stability and control in various complex terrains. At the same time, the vehicle is also equipped with full-cover chain protection, which effectively prevents the chain from being damaged by the intrusion of debris such as mud and sand.
In terms of comfort, the AG200 YAMAHA Motorcycle also performs well. Its wide and fluffy seat provides good support and comfort for the driver. At the same time, the vehicle is also equipped with a dedicated fuel tank to ensure long-term endurance. In addition, the rear seat of the vehicle is factory-set to carry luggage, so a large metal rear bracket is equipped at the back to facilitate the driver to carry various tools and items.
Model: JL200-9F
|
Overall Length(mm): |
2090x800x1240mm |
|
Wheelbase(mm): |
1375mm |
|
Ground Clearance(mm): |
130mm |
|
Dry Weight(kg) |
105kg |
|
Max. Load Mass(kg): |
150kg |
|
Max. Speed(km/h): |
90km/h |
|
Tire: |
Front: 80/100-21 Rear:110/100-18 |
|
Driving Mode: |
By Chain |
|
Brake Mode: |
Front: Drum/drum Rear: Drum |
|
Brake Operation Mode: |
Front: Hand Rear: By Foot |
|
Engine Type: |
1 Cylinder Four Stroke |
|
Cylinder Type: |
Vertical type |
|
Piston Displacement: |
200cc |
|
Compression Ratio: |
9.5:1 |
|
Max. Torque(N.M/rpm): |
14.50/6000(N.M/rpm) |
|
Lubrication: |
Compress & Splash Combined Type |
|
Max. Output Power(kw/rpm): |
11.2/7500(kw/rpm) |
|
Ignition: |
C.D.I |
|
Started System: |
Electric Starter/Kick Starter |
|
Engine Cooling: |
Forced Air Cooling |
|
Transmission: |
International Gearshift |
|
Clutch: |
Manual, Wet, Multi-Disc |
|
Battery: |
12V-6.5AH |
|
Fuel Capacity: |
12L |
|
Average Consumption: |
2.0L/100km |
|
Shipping Size: |
(Front wheel, handlebar and shift stick knocked down) |
|
Packing Size(LxWxH)(mm): |
1580 X 470 X 850 mm |
|
Weight: Net Weight: 105kgs |
Gross Weight: 135kgs |
|
20’FCL: |
36 units |
|
40’FCL: |
72 units |
|
40’HQ: |
108 units |
